ABS Material RFID Token Tag For Entrance Guard Paw Patrol Points

ABS Material RFID Token Tag For Entrance Guard Paw Patrol Points

Shot Description:

ABS Material RFID Token Tag For Entrance Guard Paw Patrol Points The Coin Tag is designed as a tag for warehouse managerment, and property tracking, it can be install on the pallet, the cartons, the machine etc. To handle harsh warehouse/ factory environment, the tag is optional with filling epoxy technics, it would made the tag complete water/ oil proof. The tag is also optional with anti-metal layer to mount…

Description:

ABS Material RFID Token Tag For Entrance Guard Paw Patrol Points

The Coin Tag is designed as a tag for warehouse managerment, and property tracking, it can be install on the pallet, the cartons, the machine etc. To handle harsh warehouse/ factory environment, the tag is optional with filling epoxy technics, it would made the tag complete water/ oil proof. The tag is also optional with anti-metal layer to mount and working on metal surface.

Features:

1. Size:30*5mm,35*8mm,40*5mm,50*8mm

2. Weight: 3g-10g

3. Material: ABS

4. Color: black,white,customized

5. Use Temperate: -20°C-120°C

6. Water-proof, moisture-proof,shock-proof, high temperature resistance.

7. Wide used to Door control,Conference,Product Anti-forgery, Logistic Tracking, Identification, Industrial automation, Game counter,Ticket,Patrol etc.

8. Operation Frequency: (LF)125KHz,(HF)13.56MHz,(UHF)915MHz

9. Chips Available: EM4100, EM4102, EM4450, TK4100, T5557, Hitag1, Hitag2, Hitag S, FM1108,FM1208,S50,S70,ICODE1,ICODE2,Ti2048,Ti256,SR176,INSIDE2K,LRI2K,LRIS2K,Ult ralight10,Impinj Monza,Alien,NXP etc.

10. Writing Cycle: 100,000 times

11. Printing: Silk-screen printing with logo/ Ink-jet printing or Thermal transfer printing or Laser process of Serial Number / Chip encoding / Laser Logo.

1.MaterialAntenna MaterialCopper foil
Surface materialABS
2.Chip AvailableEM4100, EM4200, etc
3.RFID ParametersFrequency125KHz
ProtocolISO 18000-2
Operation distanceUp to 5CM (depending on antenna geometry)
Data retention10 years
4.DimensionSizeDiameter 29.5mm
5.CraftsUID Code,Serial NO,Laser Code, Logo Printing, Barcode Printing, QR code printing, etc.
6.PrintingCMYK printing/Silk-screen printing/Digital printing
7.EnvironmentWorking temperature-30°C~+75°C
