IP65 Long Range UHF RFID Reader Andriod Handheld PDA

IP65 Long Range UHF RFID Reader Andriod Handheld PDA

Shot Description:

IP65 Long Range UHF RFID Reader Andriod Handheld PDA This is a powerful Industrial Handheld with Quad-core, Dual-SIM and 4G communication. It is with 1280*720dpi high resolution, 5″ large screen, latest Android 5.1 OS. 1D/2D barcode reader, NFC and UHF RFID are optional. Support WIFI, Bluetooth, GPS+BDS and other functions. Basic Parameters                                                                               Type IOT Handheld Terminal CPU Quad-Core ARM Cortex A7 1.3GHz Graphics Processor Mali760-MP2 Memory 2G LPDDR2 RAM+16G EMMC…

Description:

IP65 Long Range UHF RFID Reader Andriod Handheld PDA

This is a powerful Industrial Handheld with Quad-core, Dual-SIM and 4G communication. It is with 1280*720dpi high resolution, 5″ large screen, latest Android 5.1 OS. 1D/2D barcode reader,

NFC and UHF RFID are optional. Support WIFI, Bluetooth, GPS+BDS and other functions.

Basic Parameters
TypeIOT Handheld Terminal
CPUQuad-Core ARM Cortex A7 1.3GHz
Graphics ProcessorMali760-MP2
Memory2G LPDDR2 RAM+16G EMMC ROM
OSAndroid 5.1- Android 6.0
ColorBlack and grey
White and blue: use antibacterial material, especially for healthcare industry
Display5” high-resolution Multi-touch screen; Resolution: 1280*720 dpi
Input MethodHandwriting ,Stroke,Pinyin input method
CommunicationGSM / WCDMA / FDD / TDS / TDD;
GSM Quad Band, TDS B34/39, WCDMA B1/2/5/8, TDD B38/39/40, FDD B1/3/7/8/20
GPSBuilt-in GPS, support A-GPS, GPS+BDS, Meter Level Localization
PortMicro USB2.0, support OTG
Memory InterfaceMicro SD card, expansion: 2G to 32G
Bluetooth Bluetooth 4.0+EDR
SpeakerSingle speaker,8±15% ohm
WLANSupport 2.4G+5G, Support 802.11a/b/g/n mode and WEP.
WPA/WPA2-PSK/WAPI PSK/802.1*EAP Encryption protocol
Camera8.0 Mega Pixel rear camera; 2.0 Mega Pixel front camera; Auto focus; with LED light
BatteryLi-Polymer 4000mAh
Standby TimeOne week
Duration20 hours ( full function )
Certification/
Protection
3C,CE / IP65
IOT Functions(RFID, Barcode)
IOT Barcode1D Laser Scanning module,2D Scanning module
1D BarcodeCode128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codebar, Interleaved 2 of 5, China post 25,

ISBN/ISSN, Code93, UCC/EAN-128, GS1 Databar, HIBC, etc

2D BarcodeHoneywell / MOTO 2D Scanning module; Support both 1D and 2D; Support Code: QR,PDF417 Code128,

EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codebar, Interleaved 2 of 5, China post 25, ISBN/ISSN, Code93, UCC/EAN-128, etc

IOT RFID* Fully support NFC. Support 14443A/B,15693 Protocol, Reading Distance 2cm~5cm, reading position, battery cover.
* Built-in UHF RFID (EPC C1/G2, 18000-6C Protocol), reading and writing tags (optional).
Working Conditions
Operation Temperature-25 ~ 65 ºC
Storage Temperature-30 ~ 70 ºC
Humidity0 ~ 95%
Product Features
Gravity Sensor  SupportLight Sensor     SupportDistance Sensor  SupportReceiver       Support
Microphone     SupportHeadset         SupportVibrator        Support
ModelOptional Standard
C5S Series1D Laser Scanning module
2D Scanning module
UHF RFID
Quad-Core,NFC,Bluetooth 4.0,WIFI2.4G+5G,GPS+BDS,CDMA GSM,8.0 Mega Pixel rear camera,

2.0 Mega Pixel front camera

QQ截图20190709092541

QQ截图20190709092630
