ISO15693 I Code Sli Pet RFID Tags Passive RFID Sticker

ISO15693 I Code Sli Pet RFID Tags Passive RFID Sticker

Shot Description:

ISO15693 I Code SLI PET RFID Tags Passive RFID Sticker The ICODE SLIX-S IC is a dedicated chip for smart label applications with the need for a higher security level, larger memory and/or a product which takes care of the increasing demand for perfect customer privacy. This IC is the third generation of a product family of smart label ICs based on the ISO standards ISO/IEC 15693 With 50 years…

Description:

ISO15693 I Code SLI PET RFID Tags Passive RFID Sticker

The ICODE SLIX-S IC is a dedicated chip for smart label applications with the need for a higher security level, larger memory and/or a product which takes care of the increasing demand for perfect customer privacy. This IC is the third generation of a product family of smart label ICs based on the ISO standards ISO/IEC 15693

With 50 years guaranteed data retention they are the ideal choice for libraries, archives and other long-term applications.

PET substrate and aluminum coating metal etching process production Or PI and copper antenna, That with good waterproof, dust proof performance.

Name ICODE SLIS label
Material PET
Dimension CUSTOMED
Application - Automatic production management
- Asset tracking
- Device embedded
- Material identification
Treatment Printing,Encoding, Encryption,etc.
Personlize Adhesive, anti metal, etc
Chip Frequence 125KHZ,132.5KHZ,13.56MHZ,860-960MHZ
Structure Gluing, lamination
Optional Characters Anti-tearing strength, waterproofing, friction resistance, sunlight resistance, bend resistance,etc.
Read range From 1mm to 10meters upon different frequence chips
MOQ Usually 1000pcs per item for custom, discussed for stock

Applications:

Libraries
Healthcare
Document tracking
Pharmaceuticals
Factory automation
Casino gaming
Product authentication

Key Features:

Market-leading RF performance
Full backwards compatibility with installed SLI solutions
High reliability of communication
50 years data retention
All SLIX products are available in standard and high capacitance variants
Optional 32 bits password protection
EAS, AFI features
User memory: 256 to 1280 bits
RF interface: ISO15693, ISO 18000-3.1
Anti-collision performance: 60 tag/s
Package options: sawn wafer, FCS, SOT1122 package

Packages:

By Roll / Sheet / Full Sheet
The Diameter of the roll is 3 inch
1000PCS / roll (or 500PCS / roll)
Wrap-Shrink
1000PCS / carton; 3000PCS / carton;
5000PCS / carton; 10000PCS / carton

About us: Shenzhen A.N.G Technology CO., Ltd located in Shenzhen, is a high-tech manufacturer specialized in production Radio Frequency Identification Smart Card, NFC Label and Card Reader.

Model Label Size(mm) Antenna Size(mm) S50 Ultralight FM1108 I-Code2 H3/H4 M4/M5
Windshield Tag 100*100 93*19 N N N N Y N
Windshield Tag 102*77 80*40 N N N N Y Y
Anti-Tear Label 50*50 45*45 Y Y Y Y Y Y
On-Metal Tag 50*35 37*22 Y Y Y Y N N
Gas Cylinder Tag 46*31 37*22 Y Y Y Y N N
Library Label Tag 45*45 Φ40 Y Y Y Y N N
DVD Label Φ45 Φ40 Y Y Y Y Y Y
Bottle Tag 130*30 119*21 N N N Y Y Y
Jewelry Label 120*15 83*11 N N N N Y N
Label/Inlay Φ40 Φ34 Y Y Y Y N N
Label/Inlay Φ25 Φ22 Y Y Y Y N N
Label/Inlay 18*18 15*15 Y Y Y Y N N
